VORTEX DIAMONDBACK HD BINOCULARS

The Diamondback HD smashes the scale of price vs performance, delivering a rock-solid optic that optically punches high above its class. The included GlassPak binocular harness keeps your glass close at hand, ready to deploy at a moment's notice, all while providing protection and significantly more comfort than traditional neck straps.

FEATURES

HD Optical System
Fully Multi-Coated
Dielectric Coating
ArmorTek
Phase Correction
Rubber Armor
Waterproof
Shockproof
Fogproof
Roof Prism
Magnesium Chassis
Adjustable Eyecups
Center Focus Wheel
Diopter
Tripod Adaptable

TECH SPECS

Model	Magnification	Objective Lens Diameter	Eye Relief	Exit Pupil	Linear Field of View	Angular Field of View	Close Focus	Interpupillary Distance	Height	Width	Weight
8x28	8x	28mm	18mm	3.5mm	332ft/1000yds	6.2°	6ft	55-72mm	4.6in	4.5in	14oz
10x28	10x	28mm	16mm	2.8mm	273ft/1000yds	5.1°	6ft	55-72mm	4.6in	4.5in	15.9oz
10x42	10x	42mm	15mm	4.2mm	330ft/1000yds	6.3°	5ft	55-73mm	5.7in	5.1in	21.3oz
10x50	10x	50mm	17mm	5mm	315ft/1000yds	6.0°	6ft	60-75mm	6.6in	5.3in	30oz
12x50	12x	50mm	14mm	4.2mm	271ft/1000yds	5.2°	6ft	60-75mm	6.4in	5.3in	28.9oz
15x56	15x	56mm	15.6mm	3.7mm	230ft/1000yds	4.36°	14ft	59-76mm	7.1in	5.8in	34.8oz

Expand

15x56

Magnification: 15x
Objective Lens Diameter: 56 mm
Eye Relief: 15.6 mm
Exit Pupil: 3.7 mm
Linear Field of View: 230 ft/1000 yds
Angular Field of View: 4.36 degrees
Close Focus: 14 feet
Interpupillary Distance: 59-76 mm
Height: 7.1 inches
Width: 5.8 inches
Weight: 34.8 oz

12x50

Magnification: 12x
Objective Lens Diameter: 50 mm
Eye Relief: 14 mm
Exit Pupil: 4.2 mm
Linear Field of View: 271 feet/1000 yards
Angular Field of View: 5.2 degrees
Close Focus: 6 feet
Interpupillary Distance: 60-75 mm
Height: 6.4 inches
Width: 5.3 inches
Weight: 28.9 oz

10x50

Magnification: 10x
Objective Lens Diameter: 50 mm
Eye Relief: 17 mm
Exit Pupil: 5 mm
Linear Field of View: 315 feet/1000 yards
Angular Field of View: 6.0 degrees
Close Focus: 6 feet
Interpupillary Distance: 60-75 mm
Height: 6.6 inches
Width: 5.3 inches
Weight: 30 oz

10x42

Magnification: 10x
Objective Lens Diameter: 42 mm
Eye Relief: 15 mm
Exit Pupil: 4.2 mm
Linear Field of View: 330 feet/1000 yards
Angular Field of View: 6.3 degrees
Close Focus: 5 feet
Interpupillary Distance: 55-73 mm
Height: 5.7 inches
Width: 5.1 inches
Weight: 21.3 oz

10x28

Magnification: 10x
Objective Lens Diameter: 28 mm
Eye Relief: 16 mm
Exit Pupil: 2.8 mm
Linear Field of View: 273 feet/1000 yards
Angular Field of View: 5.1 degrees
Close Focus: 6 feet
Interpupillary Distance: 55-72 mm
Height: 4.6 inches
Width: 4.5 inches
Weight: 15.9 oz

8x28

Magnification: 8x
Objective Lens Diameter: 28 mm
Eye Relief: 18 mm
Exit Pupil: 3.5 mm
Linear Field of View: 332 feet/1000 yards
Angular Field of View: 6.2 degrees
Close Focus: 6 feet
Interpupillary Distance: 55-72 mm
Height: 4.6 inches
Width: 4.5 inches
Weight: 14 oz
